CyberRow

Server rack cooling with innovative air conduction

To Contact Form

CyberRow solutions are ideal for high density, row-based data center cooling, in open and contained applications.

CyberRow provides intelligent airflow control for more efficient rack cooling, with or without containment.

Data center
Data center
Our units are designed for highest requirements and maximum reliability
Small, medium & large rooms
Small, medium & large rooms
Precision air conditioning units for low to high heat loads
Virtual Containment
Virtual Containment
Separation of air flows without structural measures

Product Overview

At a glance

Most important benefits

  • Suitable for server rack cooling in data centers with or without raised floor
  • Indirect Dynamic Free Cooling for maximum potential savings
  • Targeted cooling of high-density racks

Most important features

  • Can be used with racks from any manufacturer
  • Individual supply air boost in three horizontal zones

Most important technical data

  • Cooling capacity (kW): 11 – 58
  • Air conduction: left and right, left, right, forward
Benefits
  • Suitable for data centers with or without raised floor
  • Indirect Dynamic Free Cooling for maximum potential savings
  • Targeted cooling of high-density racks
  • Each unit can cool up to six server cabinets
  • Innovative technology and high-quality components keep server rack cooling system’s energy consumption to a minimum
  • Two mutually independent setpoints ensure precise temperature control
  • Up to five independent, variable-speed EC fans for need based cooling in three horizontal zones
  • Variable-speed EC compressor for precise cooling capacity and integrated soft start
  • Easy maintenance thanks to access from the front and rear of the unit
Features
  • Can be used with racks from any manufacturer
  • Server rack cooling including individual supply air boost in three horizontal zones
  • Available in three widths and two depths
  • Available in 5 different cooling systems
  • Optimized cooling air pattern creates a virtual containment
  • Easy integration into hot and cold aisle containments
  • RS485 connectivity to standard BMS systems
  • Zigzag G4 filter with metal frame
  • Powder-coated housing with doors at front and rear
  • Pre-cut openings as standard for water connections top and bottom
  • No direct cable or refrigerant connections are required between the rack and the A/C unit, allowing greater flexibility for installation in the Data Center
  • Pivoting E-box (for service and maintenance)
Technical Data
Cooling capacity total (kW)11 – 58
Air conductionleft and right, to the left, to the right, forward
Airflow volume (m³/h)3,200 – 11,200
Sizes6
DimensionsHeight (mm): 1,950

Width (mm): 300 – 600

Depth (mm): 1,200 – 1,375
Cooling SystemsAir-cooled (A/AS), Water-cooled (GS), Hybrid Free Cooling system (GES), Chilled water system (CW/CW2)
Refrigerants

R410A (GWP: 2,088)

R134a (GWP: 1,430)
